SQD-LW200WH LED Panel

SQD-LW200WH LED Panel

Product Description:

The light source USES 960 LED beads, high light efficiency, good heat dissipation, long life (100000 hours), continuous work for three years, the light decline does not exceed 12%

The output flux after passing through the soft plate is greater than 19000 lumens

According to the structural characteristics of the product and the characteristics of the light source heating special design custom heat dissipation aluminum and fan, good heat dissipation, low noise, the product working noise is not 20db

Unique structural design, shading and soft light can be replaced at will

16bit dithering smooth linear dimming, dimming does not delay, refresh frequency more than 20KHz

High quality, no ghosting, no glare, high degree of reduction

When many lamps are dimming synchronously, the color temperature and color rendering index are consistent

RDM function

Technical Parameters:

‍

• Input  AC100~240V, 50~60Hz

• OUTPUT:200W

• Color temperature:3200K/5600K available

• CRI:≥95,full light general light source, R9≥95, R11≥93, R12≥91, all other R values ≥97

• TLCI:≥ 93

• Beam Angle:105°(Half the peak Angle)

• Control:DMX or manually

• Dimming: no jitter smooth linear dimming above 16 bits, dimming frequency above 20K

• Channels:1CH

• Working temperature: 0℃ to 40℃

• 100,000 hours of LED lifetime

• Dimensions: 560L×146W ×358H (mm)with barn door,560L×107W× 343H (mm)without barn door

• NET WEIGHT：9kg
