Radiator profile and lamp structure integrated design, good heat dissipation effect, no noise; Widely used in television studios, halls, multimedia meeting rooms, recording studios, video classrooms, theater auditorium and other places.
Power supply: AC100-240V~ 50/60Hz and DC61V dual power supply uninterrupted working mode
Power: 120W
Light source: 324*0.5W full spectrum, high display finger LED patch lamp beads
Color temperature: 3200K/5600K /3200K-5600K adjustable
Beam Angle: 120°
Color rendering index: ≥95, R9≥93
Dimmer refresh frequency: 16K/24K/32K optional, high frequency control technology system ensures no flicker and no jitter
Dimming accuracy: level 30000/level 55000 (optional)
Dimming: 0-100% linear dimming , 3 dimming curves optional
Control mode: DMX512, RDM function
Control channel: 1CH, 3CH (single-color temperature) optional, 2CH, 5CH, 6CH (two-color temperature) optional
Built-in temperature protection sensor overtemperature protection
Power off protection control: The use of dual power synchronous work management technology, in case of sudden power off, the equipment continuously keep working for 1-3 hours
Drive mode: constant current drive
Display mode: LCD screen
Light guide plate: imported opalescent PC light guide plate, to solve the glare problem
Heat dissipation mode: Fan-less integrated aluminum alloy heat dissipation system, natural heat dissipation through air convection
Shell material: aluminum alloy profile + high conductivity aluminum alloy substrate integrated structure, efficiently meet the lamp body fast conduction lamp bead heat
IP Rating: IP20
Size(W×D×H): 550×320×115mm
Weight: 9.5kg
