Radiator profile and lamp structure integrated design, heat dissipation effect is good, meet the requirements of high power heat dissipation;Widely used in TV studio, hall, multimedia conference room, recording studio, electric classroom, theater auditorium and other places.
Power supply: AC100-240V~ 50/60Hz
Power: 160W/250W/350W/400W
Light source: 324 /576 /864 /1152*0.5W LED optional
Color temperature: 3200K/5600K/3200K-5600K adjustable color temperature, three optional
Beam Angle: 120°
Color rendering index: ≥95, R9≥93
Dimmer refresh frequency: 16K/32K(optional)
Dimming accuracy: level 30000/level 65000 (optional)
Dimming: 0-100% linear dimming (2 dimming modes, 3 dimming curves)
Control mode: DMX512, RDM function, Touch screen/separate control with dual knob potentiometer optional
Control channel: 1CH, 4CH, 6CH(optional)
Drive mode: constant current drive
Display mode: LCD screen
Light guide plate: high efficiency opalescent PC light guide plate can solve glare problem
Heat dissipation: heat conduction of aluminum profiles, natural heat dissipation without fan box
Shell material: aluminum + light guide plate
IP Rating: IP20
Size(W×D×H): 550×320×115mm(160W without barndoors);
810×628×402mm(160W with barndoors);
575×320×115mm (200W without shutters);
832×628×402mm (200W including shutters);
815×320×115mm (300W without shutters,);
1072×628×402mm (300W including shutters);
1065×320×115mm (400W without shutters);
1322×628×402mm (400W including shutters)
Weight: 7.5kg(160W), 12.5kg(200W/300W/400W)
