SQD-TH3096 LED PAR

High performance COB curing module, high efficiency, more than 25000 hours of service life;International standard DMX512 control mode, PWM digital system dimming, good linearity, no jitter;Constant voltage and constant current drive, the relevant optical indicators remain stable, dimming process will not produce changes. It is suitable for all stages, TV stations and professional venues.

SQD-TH3096 LED PAR
Product Description:
High performance COB curing module, high efficiency, more than 25000 hours of service life;International standard DMX512 control mode, PWM digital system dimming, good linearity, no jitter;Constant voltage and constant current drive, the relevant optical indicators remain stable, dimming process will not produce changes.
It is suitable for all stages, TV stations and professional venues.
Technical Parameters:
- Power supply: 100 ~ 240V AC, 50/60Hz
- Power: 300W, power factor PF≥0.98
- Light source: 96 ×3W LED (24R, 24G, 24B, 24W)
- Life: ≥50000 hours
- Luminous flux: 17600 lm
- Color temperature: 3000K~8000K linear adjustment
- Lens: bead lens
- Beam Angle: 110°
- Dimming: 0-100% linear dimming
- Stroboscopic effect: 0~20 times/second
- Control mode: DMX512
- Tilt Angle: +/ -90 °
- Heat dissipation: new and reliable air convection cooling mute mode, no fan, low noise
- Protection grade: Ip65
- Working environment temperature: -30℃~45℃
- Housing: Aluminum Alloy
- Color of lamp body: black
- Size: 517×221×306 mm
- Weight: 17.8 kg
